Milwaukee Milvaco 1550CB2HWM040 4" Gate Valve
Milwaukee Valve Gate Valve, Outside Screw and Yoke, Series: 1550, 4 in Nominal, Flanged End Style, 150 lb Pressure Class, -20 to 800 deg F, Handwheel Actuator, 9 in Inlet to Outlet Length, 21.73 in Top to Inlet Center, Cast Steel Body, Forged Steel Stem Trim, Graphite Softgoods, 9.84 in Diameter Hand Wheel
| Actuator Type | : | Handwheel |
| Body Material | : | Cast Steel |
| End Style | : | Flanged |
| Hand Wheel Diameter | : | 9.84 in |
| Inlet to Outlet Length | : | 9 in |
| Nominal Size | : | 4 in |
| Pressure Class | : | 150 lb |
| Series | : | 1550 |
| Softgoods Material | : | Graphite |
| Temperature Rating | : | -20 to 800 deg F |
| Top to Inlet Center | : | 21.73 in |
| Trim Material | : | Forged Steel Stem |
| Type | : | Outside Screw and Yoke |
- Flexible wedge for improved seating
- 2 bolt adjustable stem packing arrangement for longer packing life
- Stem have grounded finish for improved packing seal
